| ब्रांड नाम: | Casun |
| मॉडल नंबर: | 57BL52R63-2460-25P |
| MOQ: | 1पीसी |
| कीमत: | $3.14-$5 |
| भुगतान की शर्तें: | डी/ए, टी/टी, एल/सी, डी/पी |
| आपूर्ति की योग्यता: | 40000+पीसी+महीना |
Widely used in environments that require moisture and water resistance, such as outdoor equipment, medical devices, industrial automation, etc.
It can prevent electrical short circuits and other safety hazards, improving the overall safety of the equipment.
Features:
|
Fram Size
|
57 mm |
|
Rated Current
|
4 A |
|
MaTorque
|
0.3N.m |
|
Resistance
|
6000rpm |
|
Inductance
|
6500rpm |
|
Rate Power
|
63 W |
|
Rate Voltage
|
24 V |
|
Number of poles
|
4 |
|
Insulation Class
|
Class B |
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
| Model | Holding Torque | Step Angle | Length | Type of Shaft | Rated Current |
| 57SHD4013-21B | 0.6N.m | 1.8° | 41mm | D Shaft-21mm | 1.0A |
| 57SHD4415-21B | 1.1N.m | 1.8° | 54mm | D Shaft-21mm | 3.0A |
| 57SHD4816-21B | 2.0N.m | 1.8° | 76mm | D Shaft-21mm | 3.0A |
| 57SHD4913-21B | 2.5N.m | 1.8° | 83mm | D Shaft-21mm | 3.0A |
| 57SHD4934-20B | 3.0N.m | 1.8° | 100mm | D Shaft-20mm | 3.0A |
