| ब्रांड नाम: | Casun |
| मॉडल नंबर: | 28SHD0405-15B |
| MOQ: | 1पीसी |
| कीमत: | $23.94-$28.34 |
| भुगतान की शर्तें: | डी/ए, टी/टी, एल/सी, डी/पी |
| आपूर्ति की योग्यता: | 40000+पीसी+महीना |
Nema11 28X28MM Hybrid Stepper Motor
The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.
Use with a microstepping driver to reduce vibration and achieve higher step resolution.
Choose a baseline version or request your own customized configuration.
Features:
|
Step Angel
|
1.8 ° |
|
Rated voltage
|
3.83 V DC |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
1.5Amp |
|
Holding Torque
|
100mN.m |
|
Detent torque
|
5mN.m |
|
Phase resistance
|
2.7ohm±10%(At 20℃) |
|
Phase inductance
|
1.9mH±20%(1kHz rms) |
|
Rotor inertia
|
9g.cm |
|
Motor weight
|
0.16kg |
|
Insulation resistance
|
100MΩmin.(500V DC)
|
|
Insulation class
|
Class B |
